HONEYWELL BW MicroClip X3

Description

The Honeywell BW MicroClip X3 is a rugged, wearable 4-gas portable detector that delivers reliable personal safety monitoring in demanding industrial environments. Designed for simultaneous detection of oxygen (O2), combustible gases (% LEL), hydrogen sulfide (H2S), and carbon monoxide (CO), it features a compact, ergonomic one-button design, intuitive LCD readout, and bright audible/visual/vibration alarms. With IP68 water and dust resistance, 18-hour battery life, and a 3-year warranty including a long-life oxygen sensor, the X3 is built for continuous daily use while simplifying compliance and device management with Honeywell’s SafetySuite and IntelliDoX connectivity.

Specifications

Product information

Technical Specifications

Specification	Value
Gases Detected & Sensor Range
Oxygen (O2)	0–30.0 % vol
Combustible Gases (% LEL)	0–100 % LEL / 0–5.0 % v/v
Hydrogen Sulfide (H2S)	0–100 ppm
Carbon Monoxide (CO)	0–500 ppm
Sensor Type & Life	Long-life sensors with expected 5-year service lifetime (O2 sensor included)
Battery / Runtime	Rechargeable lithium polymer — ~18 hours typical runtime; recharges in 6 hours
Alarms	Audible (~95 dB), visual, and vibrating; low/high/TWA/STEL/OL alarm setpoints
Display	Continuous LCD with real-time gas readings
Ingress Protection	IP68 (water & dust resistant)
Dimensions	~11.3 × 6.0 × 3.2 cm / 4.4 × 2.4 × 1.2 in
Weight	~179 g / 6.3 oz
Operating Temp	–20 °C to +50 °C (–4 °F to 122 °F)
Humidity	0–95 % RH (non-condensing)
Wireless & Software	BLE connectivity; compatible with Honeywell SafetySuite device management and IntelliDoX automatic test/calibration stations
Certifications	ATEX, IECEx, CSA Class I Div. 1 Groups A, B, C, D, CE conformity
Warranty	Full three (3) year warranty including all sensors
